IM-R-DR

Product details

Refrigerated Multi-Deck Self-Service Merchandiser with EcoVision Doors for Prepared Food, Deli, Meat, Dairy, Bakery, Beverage, and Produce Applications

Heights.

  • 58" (05)

Types.

  • End (E)
  • Center (C)
  • In-Line (l)

Lengths.

  • End: 5' (IM-05-E5-R-DR)
  • Center: 4', 5', 8', 12' (IM-05-C4-R-DR), (IM-05-C5-R-DR), (IM-05-C8-R-DR), (IM-05-C12-R-DR)
  • Inline: 4', 5', 8', 12' (IM-05-I4-R-DR), (IM-05-I5-R-DR), (IM-05-I8-R-DR), (IM-05-I12-R-DR)

Features.

  • Ecovision doors
  • EcoShine II Plus LED mullion and canopy lights
  • Narrow 24" and 30" (3' height) french doors
  • No heat required w door frames
  • Painted exterior
  • Modular coil system – 5 year warranty
  • Energy efficient fans
  • Solar digital thermometer
  • Please reference color chart for choice of standard Hussmann paint and finish options

Options.

  • 18" adjustable shelves with tag molding Liquid line hand valve
  • Thermostat
  • End panel, flush (inline)
  • View ends
  • End panel with wrap around bumper (inline)
  • Solid transition panel (between dissimilar temp modules)
  • Finished exterior back cover (inline): painted, stainless steel
  • Special interior and exterior finishes* (consult your Hussmann sales representative)

* Some optional features may need to be certified by UL, NSF, and/or other 3rd party certification agencies. Contact Hussmann for verification or questions for availability.

† Only lighting configurations that are compliant with the U.S. Dept. of Energy (DOE) 2017 regulation are available for sale for use in the U.S.A.

Case Department Deli, Bakery, Prepared Foods, Meat, Dairy
Case Function Self-Service
Case Temperature Medium Temp
Case Type Multi-Deck, Isla
Installation and Operation Manuals
